Standard Feature:
- The machine can automatically complete the products conveying, measuring, and feeding, filling and bag forming, date code printing, bag sealing and cutting.
- Servo-motor driven, twin belt film pulling system.
- High sensitive fiber optic photo sensor can automatically trace color mark accurately.
- PLC control system combined with touch screen, can easily set and change the packing parameters. Daily production output and self-diagnostic machine error can be viewed directly from the screen.
- PID temperature controller monitors heat sealing temperature within ±1°C.
- Selected electrical and pneumatic components from reliable international manufacturer.
- Sealing at 4 corners, Box style pouch look nicer and higher quality
- Inclined design, better solution for easy break products (option)
- With CE Certificate comply with CE standard
Optional Parts:
- Inclined design
- Date code printer
- Stainless steel case
- Pouch clipping device
- Zipper bag device
- Fix degree inclined design (For fragile products packing)
| Model No. | PM-520-5S | PM-520-4S | PM-620-5S | PM-620-4S |
| Vertical sealing number | 4 corner seal and fin seal | only 4 comer seal (no fin seal) | 4 corner seal and fin seal | only 4 comer seal (no fin seal) |
| Film width (mm) | Max. 520mm | Max. 420 mm | Max. 620 mm | Max. 520 mm |
| Bag length (mm) | 200-400 | 200-400 | 200-450 | 200-450 |
| Packing speed | 20-50 ppm | 20-40 ppm | 20-40 ppm | 20-35 ppm |
Application:
Automatic packaging of granule products in formed pouch for the food, pharmaceutical, chemical and other industries. Special for biscuits, potato chips, shrimp chips, foodstuff etc.
